# Serverless之快速搭建Spring Boot应用 Serverless，也就是无服务器，什么是无服务器，和服务器有什么关系，为什么需要Serverless，怎么使用Serverless，这些问题将是本篇文章得到答案。在本篇文章中会简单介绍Serverless的基础概念和利用Serverless快速搭建Spring Boot应用。 ## 1. 什么是无服务器 (Serverless) ### 1.1 基础概念 现在正常的开发发布流程是首先编码，然后把代码打包成镜像，服务器拉取最新镜像重启更新，我们不仅需要编码，还需要考虑服务器的部署，应用日志，扩容，负载均衡等等，那么有没有什么新的架构能帮助我们省去运维，让开发只关心编码，测试，这就是Serverless。 **Serverless（无服务器架构）指的是服务端逻辑由开发者实现，运行在无状态的计算容器中，由事件驱动， 服务器完全被第三方管理，而业务层面的状态则记录在数据库或存储资源中。** 用一句话说，就是让开发者只需要关注业务实现，不必要关心与业务无关的东西，比如考虑如何部署到云端，不需要关心扩容，不需要关心运维，这一切东西全部交给提供Serverless的云服务提供商。 与IaaS的区别是，在IaaS中，用户需要提前购买好服务器，并且在请求高的时候提高资源，在请求低的时候减少资源，在没有请求的时候，容器依然就绪等待请求。 Serverless不需要提前购买服务资源，只在需求时启动，在事件触发时分配资源，当没有事件触发时就会关闭容器，等待下一次触发。那么开发者需要做的就是用代码实现业务，然后把代码打包上传到云服务提供商就结束了，剩下的运维全部交给提供商。 ### 1.2 优缺点 首先，我们看看Serverless有哪些缺点： 1. 冷启动。Serverless 也是在容器中运行应用的。当某个请求传入时，会首先检查是否有正在运行的容器，如果没有正在运行的容器，就会启动一个新的容器去运行应用，这个就是冷启动。既然需要启动新的容器，那么响应的时间就不会那么快。 2. 切换成本高。由于使用的是云服务商提供的服务，当我们需要更改服务商的时候，成本就会非常高，因为每一家的规范都不相同。 3. 不灵活。与方便对应的就是不灵活，因为我们所以的运维都交给了提供商，那么我们就不能控制服务器或者优化服务器达到我们的目的。 再来看看优点： 1. 提高开发效率，这个在前面已经说过多次，就不再赘述。 2. 降低运维成本，不需要管理服务器，只需要为运行时间付费即可。 ### 1.3 适用场景 既然有这些优缺点，那么哪些场景适合使用Serverless呢？ 1. 短暂，无状态的应用，可以接受冷启动的场景。 2. 不频繁但是可能请求激增的场景。 比如实时文件处理，数据ETL，无服务器移动后端，音视频分析等场景。 ### 1.4 Serverless产品 1. AWS Lanmbda：支持文件处理，流处理，Web应用程序，IoT后端，移动后端。 2. Cloud Functions：支持与第三方服务及API集成，无服务器移动后端，服务器IoT后端，文件处理，视频和图片分析，情感分析。 3. 阿里云函数计算：具有丰富的触发器类型，支持多种编程语言，有非常便捷的开发工具进行调试部署，还有丰富的计算类型 4. 腾讯云 Serverless：拥有简化配置，方便运维，一站式开发等特点，支持基于云函数的命令行开发工具，传统应用框架的快速迁移等场景。 下面我们将使用阿里云的函数计算实际部署Spring Boot应用。 ## 2. 快速搭建Spring Boot应用 阿里云的函数计算是事件驱动的全托管计算服务。使用函数计算，您无需采购与管理服务器等基础设施，只需编写并上传代码。函数计算为您准备好计算资源，弹性地、可靠地运行任务，并提供日志查询、性能监控和报警等功能。 ### 2.1 开发流程 函数计算工作流程如下图所示： ![](https://image.ldbmcs.com/2021-10-28-Nql4DJ.jpg) 1. 开发者使用编程语言编码代码，目前函数计算支持的编程语言：Java，PHP，Go，Python，Node.js等语言。 2. 开发者上传代码到函数计算，可以通过函数计算控制台，Funcraft，Serverless Devs，API或SDK等方式上传代码。 3. 触发函数执行，因为Serverless是事件驱动，所以需要通过HTTP请求，OSS、API网关等方式触发。 ### 2.2 快速部署 在这里我们通过Serverless Devs管理函数。 FC组件和ROS组件都是函数计算团队基于Serverless Devs为您提供的组件，FC组件和ROS组件是用于支持阿里云Serverless应用全生命周期的工具。该组件是Funcraft的进阶版本，和Funcraft的行为描述类似，Funcraft是通过资源配置文件template.yml协助您实现开发、构建、部署等操作的，FC组件和ROS组件则是通过资源配置文件即YAML文件，帮助您快速开发、构建、测试和将应用部署到函数计算。 #### 2.2.1 安装Serverless Devs 可以通过包管理器(npm，yarn)和脚本安装安装。这里我们通过npm安装： ```bash npm install @serverless-devs/s -g ``` 执行完成之后，通过命令`s -v`验证是否安装成功： ```bash ~ s -v @serverless-devs/s: 2.0.92, darwin-x64, node-v12.18.3 ``` #### 2.2.2 配置Serverless Devs 在使用前，我们需要先进行配置，在终端中执行`s config add`，根据提示输入`Account ID`、`Access Key Id`、`Secret Access Key`、 `aliasName` 即可。 ```bash ~ s config add ? Please select a template: Alibaba Cloud (alibaba) 🧭 Refer to the document for alibaba key: http://config.devsapp.net/account/alibaba ? AccountID 1831277402***** ? AccessKeyID LTAIkC5X***** ? AccessKeySecret ZMbINFFtAUlWPykcI51U****** ? Please create alias for key pair. If not, please enter to skip default Alias: default AccountID: 1831277402****** AccessKeyID: LTAIkC5X****** AccessKeySecret: ZMbINFFtAUlWPykcI51U******* Configuration successful ``` #### 2.2.3 创建Spring Boot项目 在目标目录下执行命令`s init devsapp/start-springboot -d projectName`初始化项目： ```bash ➜ Project s init devsapp/start-springboot -d serverlessSpringboot 🚀 Serverless Awesome: https://github.com/Serverless-Devs/package-awesome ✔ file decompression completed ? please select credential alias default _____ _ ______ _ / ___| (_) | ___ \ | | \ `--. _ __ _ __ _ _ __ __ _| |_/ / ___ ___ | |_ `--. \ '_ \| '__| | '_ \ / _` | ___ \/ _ \ / _ \| __| /\__/ / |_) | | | | | | | (_| | |_/ / (_) | (_) | |_ \____/| .__/|_| |_|_| |_|\__, \____/ \___/ \___/ \__| | | __/ | |_| |___/ Welcome to the start-springboot application This application requires to open these services: FC : https://fc.console.aliyun.com/ ACR: https://cr.console.aliyun.com/ This application can help you quickly deploy the SpringBoot project: Full yaml configuration : https://github.com/devsapp/sprintboot#%E5%AE%8C%E6%95%B4yaml SpringBoot development docs: https://spring.io/projects/spring-boot/ This application homepage: https://github.com/devsapp/start-springboot 🏄‍ Thanks for using Serverless-Devs 👉 You could [cd /Users/dcs/Project/serverlessSpringboot] and enjoy your serverless journey! 🧭️ If you need help for this example, you can use [s -h] after you enter folder. 💞 Document ❤ Star：https://github.com/Serverless-Devs/Serverless-Devs ``` 进入项目目录执行`s deploy`部署项目到函数计算，需要开通[NAS](https://nasnext.console.aliyun.com/introduction)，并创建通用型NAS文件系统。 > 阿里云函数计算支持与NAS无缝集成。这使您的函数可以像访问本地文件系统一样访问存储在其中一个NAS文件系统上的文件。您所要做的是在服务上配置NAS，其中包括NAS的地域、挂载点、分组等信息。配置成功后，该服务下的函数就可以像访问本地文件系统一样访问指定的NAS文件系统。 ```bash ➜ serverlessSpringboot s deploy [2021-10-30T21:18:13.963] [INFO ] [S-CLI] - Start ... 📎 Using web framework type: nas, If you want to deploy with container, you can [s cli fc-default set web-framework container] to switch. [2021-10-30T21:18:14.222] [INFO ] [WEB-FRAMEWORK] - The configuration of the domain name is not detected, and a temporary domain name is generated. [2021-10-30T21:18:16.653] [INFO ] [FC-DEPLOY] - Using region: cn-hangzhou [2021-10-30T21:18:16.654] [INFO ] [FC-DEPLOY] - Using access alias: default [2021-10-30T21:18:16.654] [INFO ] [FC-DEPLOY] - Using accessKeyID: ***********Udxi [2021-10-30T21:18:16.654] [INFO ] [FC-DEPLOY] - Using accessKeySecret: ***********1BwC 📎 Using fc deploy type: sdk, If you want to deploy with pulumi, you can [s cli fc-default set deploy-type pulumi] to switch. [2021-10-30T21:18:16.827] [INFO ] [FC-DEPLOY] - Checking Service web-springboot exists [2021-10-30T21:18:17.105] [INFO ] [FC-DEPLOY] - Setting role: AliyunFCDefaultRole [2021-10-30T21:18:17.152] [INFO ] [RAM] - Checking Role AliyunFCDefaultRole exists [2021-10-30T21:18:17.447] [INFO ] [RAM] - Updating role: AliyunFCDefaultRole [2021-10-30T21:18:17.561] [INFO ] [RAM] - Checking Plicy AliyunFCDefaultRolePolicy exists [2021-10-30T21:18:17.721] [INFO ] [FC-DEPLOY] - Using logConfig: auto: fc will try to generate default sls project [2021-10-30T21:18:17.892] [INFO ] [SLS] - Checking Project 1831277402525713-cn-hangzhou-logproject exists [2021-10-30T21:18:18.122] [INFO ] [SLS] - Checking Logstore 1831277402525713-cn-hangzhou-logproject/fc-service-web-springboot-logstore exists [2021-10-30T21:18:20.170] [INFO ] [SLS] - Checking Logstore index 1831277402525713-cn-hangzhou-logproject/fc-service-web-springboot-logstore exists 📎 Using fc deploy type: sdk, If you want to deploy with pulumi, you can [s cli fc-default set deploy-type pulumi] to switch. [2021-10-30T21:18:20.233] [INFO ] [FC-DEPLOY] - Generated logConfig: enableInstanceMetrics: true enableRequestMetrics: true logBeginRule: ~ logstore: fc-service-web-springboot-logstore project: 1831277402525713-cn-hangzhou-logproject [2021-10-30T21:18:20.234] [INFO ] [FC-DEPLOY] - Using vpcConfig: auto: fc will try to generate related vpc resources automatically [2021-10-30T21:18:20.976] [INFO ] [VPC] - Getting vpc: fc-deploy-component-generated-vpc-cn-hangzhou [2021-10-30T21:18:21.157] [INFO ] [VPC] - Getting vswitch: fc-deploy-component-generated-vswitch-cn-hangzhou [2021-10-30T21:18:21.272] [INFO ] [VPC] - Getting securityGroup: fc-deploy-component-generated-securityGroup-cn-hangzhou [2021-10-30T21:18:21.439] [INFO ] [FC-DEPLOY] - Generated vpcConfig: securityGroupId: sg-bp16mj0j92jm506ind4g vSwitchId: vsw-bp12p47aa34uzgsu7wic2 vpcId: vpc-bp1o9ew2j2mkrr8v5l3jz [2021-10-30T21:18:21.440] [INFO ] [FC-DEPLOY] - Using nasConfig: auto: fc will try to generate related nas file system automatically [2021-10-30T21:18:22.259] [INFO ] [FC-NAS] - Creating NasFileSystem: Alibaba-FcDeployComponent-DefaultNas-cn-hangzhou [2021-10-30T21:18:22.566] [INFO ] [FC-NAS] - Creating MountTarget: 0cb1c4b180 [2021-10-30T21:18:25.241] [INFO ] [FC-NAS] - Nas mount target domain already created, waiting for status to be 'Active', now is Pending [2021-10-30T21:18:27.505] [INFO ] [FC-NAS] - Nas mount target domain already created, waiting for status to be 'Active', now is Pending [2021-10-30T21:18:29.736] [INFO ] [FC-NAS] - Nas mount target domain already created, waiting for status to be 'Active', now is Pending [2021-10-30T21:18:31.853] [INFO ] [FC-NAS] - Nas mount target domain already created, waiting for status to be 'Active', now is Active [2021-10-30T21:18:32.091] [INFO ] [FC-DEPLOY] - Using region: cn-hangzhou [2021-10-30T21:18:32.091] [INFO ] [FC-DEPLOY] - Using access alias: default [2021-10-30T21:18:32.091] [INFO ] [FC-DEPLOY] - Using accessKeyID: ***********Udxi [2021-10-30T21:18:32.091] [INFO ] [FC-DEPLOY] - Using accessKeySecret: ***********1BwC 📎 Using fc deploy type: sdk, If you want to deploy with pulumi, you can [s cli fc-default set deploy-type pulumi] to switch. [2021-10-30T21:18:32.106] [INFO ] [FC-DEPLOY] - Checking Service _FC_NAS_web-springboot-ensure-nas-dir-exist-service exists [2021-10-30T21:18:32.178] [INFO ] [FC-DEPLOY] - Setting role: AliyunFCDefaultRole [2021-10-30T21:18:32.184] [INFO ] [RAM] - Checking Role AliyunFCDefaultRole exists [2021-10-30T21:18:32.367] [INFO ] [RAM] - Updating role: AliyunFCDefaultRole [2021-10-30T21:18:32.468] [INFO ] [RAM] - Checking Plicy AliyunFCDefaultRolePolicy exists [2021-10-30T21:18:32.602] [INFO ] [FC-DEPLOY] - Checking Function nas_dir_checker exists ✔ Make service _FC_NAS_web-springboot-ensure-nas-dir-exist-service success. ✔ Make function _FC_NAS_web-springboot-ensure-nas-dir-exist-service/nas_dir_checker success. [2021-10-30T21:18:35.575] [INFO ] [FC-DEPLOY] - Checking Service _FC_NAS_web-springboot-ensure-nas-dir-exist-service exists [2021-10-30T21:18:35.660] [INFO ] [FC-DEPLOY] - Checking Function nas_dir_checker exists There is auto config in the service: _FC_NAS_web-springboot-ensure-nas-dir-exist-service [2021-10-30T21:18:43.438] [INFO ] [FC-DEPLOY] - Using region: cn-hangzhou [2021-10-30T21:18:43.439] [INFO ] [FC-DEPLOY] - Using access alias: default [2021-10-30T21:18:43.439] [INFO ] [FC-DEPLOY] - Using accessKeyID: ***********Udxi [2021-10-30T21:18:43.439] [INFO ] [FC-DEPLOY] - Using accessKeySecret: ***********1BwC 📎 Using fc deploy type: sdk, If you want to deploy with pulumi, you can [s cli fc-default set deploy-type pulumi] to switch. [2021-10-30T21:18:43.454] [INFO ] [FC-DEPLOY] - Checking Service _FC_NAS_web-springboot exists [2021-10-30T21:18:43.527] [INFO ] [FC-DEPLOY] - Setting role: AliyunFCDefaultRole [2021-10-30T21:18:43.533] [INFO ] [RAM] - Checking Role AliyunFCDefaultRole exists [2021-10-30T21:18:43.774] [INFO ] [RAM] - Updating role: AliyunFCDefaultRole [2021-10-30T21:18:43.881] [INFO ] [RAM] - Checking Plicy AliyunFCDefaultRolePolicy exists [2021-10-30T21:18:44.044] [INFO ] [FC-DEPLOY] - Checking Function nas_dir_checker exists [2021-10-30T21:18:44.120] [INFO ] [FC-DEPLOY] - Checking Trigger httpTrigger exists [2021-10-30T21:18:44.192] [INFO ] [FC-DEPLOY] - Checking Trigger httpTrigger exists ✔ Make service _FC_NAS_web-springboot success. ✔ Make function _FC_NAS_web-springboot/nas_dir_checker success. ✔ Make trigger _FC_NAS_web-springboot/nas_dir_checker/httpTrigger success. [2021-10-30T21:18:47.007] [INFO ] [FC-DEPLOY] - Checking Service _FC_NAS_web-springboot exists [2021-10-30T21:18:47.078] [INFO ] [FC-DEPLOY] - Checking Function nas_dir_checker exists [2021-10-30T21:18:47.206] [INFO ] [FC-DEPLOY] - Checking Trigger httpTrigger exists There is auto config in the service: _FC_NAS_web-springboot [2021-10-30T21:18:47.389] [INFO ] [FC-DEPLOY] - Generated nasConfig: groupId: 10003 mountPoints: - fcDir: /mnt/auto nasDir: /web-springboot serverAddr: 0cb1c4b180-ulm3.cn-hangzhou.nas.aliyuncs.com userId: 10003 [2021-10-30T21:18:47.391] [INFO ] [FC-DEPLOY] - Checking Function springboot exists [2021-10-30T21:18:47.504] [WARN ] [FC-DEPLOY] - Image registry.cn-hangzhou.aliyuncs.com/web-framework/java11:0.0.1 dose not exist locally. Maybe you need to run 's build' first if it dose not exist remotely. [2021-10-30T21:18:47.506] [INFO ] [FC-DEPLOY] - Checking Trigger web-springboot exists [2021-10-30T21:18:47.576] [INFO ] [FC-DEPLOY] - Checking Trigger web-springboot exists ✔ Make service web-springboot success. ✔ Make function web-springboot/springboot success. ✔ Make trigger web-springboot/springboot/web-springboot success. [2021-10-30T21:18:49.288] [INFO ] [FC-DEPLOY] - Checking Service web-springboot exists [2021-10-30T21:18:49.359] [INFO ] [FC-DEPLOY] - Checking Function springboot exists [2021-10-30T21:18:49.485] [INFO ] [FC-DEPLOY] - Checking Trigger web-springboot exists [2021-10-30T21:18:49.669] [INFO ] [FC-DEPLOY] - Using customDomain: auto: fc will try to generate related custom domain resources automatically ✔ devsapp_domain.zip file decompression completed ✔ End of request ✔ Deployed. ✔ End of request [2021-10-30T21:18:57.618] [INFO ] [FC-DEPLOY] - Generated auto custom domain: springboot.web-springboot.1831277402525713.cn-hangzhou.fc.devsapp.net [2021-10-30T21:18:57.619] [INFO ] [FC-DEPLOY] - Creating custom domain: springboot.web-springboot.1831277402525713.cn-hangzhou.fc.devsapp.net ✔ devsapp_fc-domain.zip file decompression completed [2021-10-30T21:18:58.878] [INFO ] [FC-DOMAIN] - Creating custom domain: springboot.web-springboot.1831277402525713.cn-hangzhou.fc.devsapp.net There is auto config in the service: web-springboot Tips for next step ====================== * Display information of the deployed resource: s info * Display metrics: s metrics * Display logs: s logs * Invoke remote function: s invoke * Remove Service: s remove service * Remove Function: s remove function * Remove Trigger: s remove trigger * Remove CustomDomain: s remove domain Reminder nas upload instruction: upload ./code/target/demo-0.0.1-SNAPSHOT.jar /mnt/auto/springboot/demo-0.0.1-SNAPSHOT.jar Tips for next step ====================== * Invoke remote function: s invoke ✔ Upload done Tips for next step ====================== * Invoke remote function: s invoke ✔ Try container acceleration springboot: region: cn-hangzhou serviceName: web-springboot functionName: springboot customDomains: - http://springboot.web-springboot.1831277402525713.cn-hangzhou.fc.devsapp.net ``` 在浏览器中访问临时域名`http://springboot.web-springboot.1831277402525713.cn-hangzhou.fc.devsapp.net`，可以看到已经部署成功了。 ![](https://image.ldbmcs.com/2021-10-30-nEZkrO.png) #### 2.2.4 自定义域名 首先在阿里云函数计算控制台点击【域名管理】添加自定义域名。 ![](https://image.ldbmcs.com/2021-10-30-AXGLzv.png) 输入域名，选择服务名称，函数名称，版本，点击确定。注意需要提前将域名备案并解析到页面的CNAME上。 ![](https://image.ldbmcs.com/2021-10-30-vb8Nr2.png) 配置成功后就可以再浏览器中输入自定义域名验证是否配置成功。 ![](https://image.ldbmcs.com/2021-10-30-X5emqL.png) ## 3. 总结 本文介绍了Serverless是什么，解决了什么问题以及通过Serverless Devs如何快速在阿里云函数计算平台上部署SpringBoot应用。 --- # Agent Instructions: Querying This Documentation If you need additional information that is not directly available in this page, you can query the documentation dynamically by asking a question. Perform an HTTP GET request on the current page URL with the `ask` query parameter: ``` GET https://ldbmcs.gitbook.io/java/bo-ke-1/serverless-zhi-kuai-su-da-jian-spring-boot-ying-yong.md?ask= ``` The question should be specific, self-contained, and written in natural language. The response will contain a direct answer to the question and relevant excerpts and sources from the documentation. Use this mechanism when the answer is not explicitly present in the current page, you need clarification or additional context, or you want to retrieve related documentation sections.
